Description
Non-automatic bilge pumps offer traditional operation activated by a float or panel switch. Removal of the motor cartridge allows for easy cleaning of the strainer and impeller if the pump becomes clogged with debris. Electric Submersible Pumps are by far the most popular type of electric Bilge Pumps, submersibles give very high outputs, and cost-effective, have low amp draw, and are easy to install.
They are designed to fit in the lowest part of the bilge and only require discharge pipework and electricity supply. Also can be used in other applications like transferring river water, work together with solar panels or batteries. The 1-1/8″ connection will accept a 29mm ID hose. It comes pre-terminated with heavy gauge unterminated wire leads.
Features
- Meets or exceeds RoHS, SGS, and ISO standards
- Traditional operation by switch or float switch
- Compact, efficient, long-life motors
- 110°F (43°C) temperature limits
- Easy clean snap-lock strainer bases
- Anti-Airlock protection
- Run dry capable for normal workloads
- Exclusive moisture-tight seals
- Completely submersible
- Marine-grade blocked wiring
- Stainless steel shaft
- Silent and vibrationless operation
Specifications
- 12Vdc operation
- 20000 GPH
- 8.5A motor
- 29 mm/ 1-1/8″ barbed outlet
- Head approximately 5.5 meters (at maximum power input)
