Gripper - Robot Mechanical Arm Aluminum Metal Claws

https://www.ram-e-shop.com/web/image/product.template/6888/image_1920?unique=6a81919

400.00 EGP 400.0 EGP 400.00 EGP

400.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: RO.CLAW.MKII

Description:

This is Robot Manipulator Mechanical Arm Metal claws. This kit is very useful to make a robotic arm which is used in many applications like move material from one place to another place (Weight not exceeding 500 gm).

Note: The package does not contain any servo Motor you have to buy it Separately.

Features :

  • Paw Maximum Opening Angle: 55mm (without expansion board when the maximum opening angle spacing of 55mm, the largest expansion board after the installation is 95mm)
  • The plank kit is very light
  • Compatible with our Servos (MG995/MG996/FS5103/...)

SPECIFICATIONS

  • Degree of Freedom (DOF): 2
  • Paw Material: Aluminum Alloy
  • Paw Weight: about 68gm (without motor)
  • Claw Overall Length: 108mm (overall maximum length when closed paw)
  • Claw Overall Width: 98mm (maximum overall width of the paw when open)
  • Paw Maximum Opening Angle:  55mm
  • Clamp Total Length: 108mm
  • Clamp Total Width: 98mm
  • Shipment Dimensions: 10 × 6 × 4 cm
