KXN3020D Switching Single Output DC Programmable Power Supply 0~30V 0~20A

Main Functions:

• Current preset, current-limiting protection.
• Automatic switching of constant voltage/constant current.
• Three-digit display of voltage and current, with display accuracy 0.1V 0.01A
• Low noise: Temperature-controlled fan is adopted, and it starts automatically to dissipate heat when internal temperature is greater than 50℃.

Electrical Specifications:

• Model: KXN-3020D
• Input voltage: AC 220V±10% 50Hz
• Temperature: Working temperature: -10℃~40℃ Relative humidity＜80%
• Output voltage: 0-30Vdc
• Output current: 0-20Adc
• Voltage-stabilized state: Voltage stabilization degree ≤0.5% , Load stability ≤0.5%
• Ripple noise： ≤0.5%Vp-p (Peak to peak)
• Steady-flow state: Current stabilization degree ≤0.5% , Load stability ≤0.5%
• Display accuracy: 3-digit LED digital display of voltage/current ±1% ±1 character
• Display resolution: Voltage 0.1V Current 0.1A
• Boundary dimension: 366 (depth) * 198 (width) * 158 (height) mm
• Weight:  4Kg

Package includes:

• KXN3020D Main unit
• Power Cord (220 Vac)
• User Manual

Download

USER MANUAL
