Micro Switch - MS3

https://www.ram-e-shop.com/web/image/product.template/6260/image_1920?unique=c8d55bb

Limit Switch - Size 28.0 x 15.5 x 9.5 mm

12.00 EGP 12.0 EGP 12.00 EGP

12.00 EGP

Not Available For Sale

This combination does not exist.

 Pick up from RAM Store
 Shipping: 2-3 Business Days


Internal Reference: MS.3

KW(JW) series microswitch is suitable for use in each kind of control circuit with a rated voltage less than 250V and rated current less than 20A (DC and AC effective value) for controlling elements, it is the sense switch with certain movement strength through the certain traveling to cause the electronic contact speed.

  • The dimensions of this limit switch are 28.0 x 15.5 x 9.5 mm.
  • Arm length 28mm

Voltage & Current Ratings:

  • AC 125 ~ 250V - 16A
  • DC 250V - 0.30A
  • DC 125V - 0.60A
