NodeMCU V3 ESP8266 Serial Port Baseboard Lua WIFI Development Board.
Features:
- The perfect solution for breaking out the pins from Lua V3 Nodemcu.
- USB power output only for NodeMCU v3
- Lead out all the IO ports of the ESP-12E development board
- Lead out the pins of 5V and 3.3V power supply
- Convenient to connect with peripheral modules
- Onboard 5V / 1A DC-DC step-down converter circuit
- Onboard power indicator
- With DC power jack 6-24V.
- The spacing between mounting headers is 25.5 mm.
- Length: 64mm
- Width: 60mm
- Height: 14mm
NOTE: the board comes without the NODE-MCU board.
